This Cable preferably used for supplying main power / as a control cable. It can also be used for industrial installation such as in cable trench, cable duct, switchgear and in power stations. This cable is ideal for ground emplacement if a higher electrical or mechanical protection is required
Download cable specification
Conductor
Plain Annealed, Stranded Circular Non – Compacted or Circular Compacted or Shaped Copper
Insulation
PVC
Bedding
PVC or PVC Tapes
Armour
Galvanized Round Steel Wires
Sheathing
PVC
Sheath Colour
Black
Applicable Standard
BS 6346
Rated Voltage
600/1000V
Testing Voltage
3.5 KV / 5 min
Operating Temperature
Max 70º C
IEC 60332-1
IEC 60332-3-22 Cat. A (On Request)
Oxygen Index – Min. 30% (On Request)
